概述
The LP2202 is a dual channel, low noise, and low dropout regulator sourcing up to 300mA at each channel. The range of output voltage is from 1.2V to 3.6V by operating from 2.5V to 5.5V input. LP2202 offers 2% accuracy, extremely low dropout voltage (220mV @ 300mA), and extremely low ground current, only 75μA per LDO. The shutdown current is near zero current which is suitable for battery-power devices. Other features include current limiting, over temperature, output short circuit protection. LP2202 can operate stably with very small ceramic output capacitors, reducing required board space and component cost. LP2202 is available in fixed output voltages in the SOT-23-6 package.
应用
◆CDMA/GSM Cellular Handsets
◆Smart mobile phone
◆Battery-Powered Equipment
◆DSC Sensor
◆Wireless Card
数据参数
数据参数
输出电流(mA)
300
输出电压(V)
2.8/1.2,2.8/1.8,2.8/2.8
输入电压(V)
2.5~5.5
电源抑制比(dB)
-70
精度(%)
2
导通压差(mV/mA)
220 @ 300
静态电流(uA)
75
特点
Shutdown,High PSRR
封装
SOT23-6
特征
特征
◆Wide Operating Voltage Ranges : 2.5V to 5.5V
◆Low-Noise for RF Applications
◆High PSRR 75dB at 1kHz
◆No Noise Bypass Capacitor Required
◆Fast Response in Line/Load Transient
◆TTL-Logic-Controlled Shutdown Input
◆Dual LDO Outputs (220mV/300mA)
◆High Output Accuracy 2%
◆Ultra-low Quiescent Current 75uA
◆Thermal Shutdown Protection
◆RoHS Compliant and 100% Lead (Pb)-Free
