概述
The LP3995 is designed for portable applications with demanding performance and space requirements. The LP3995performance is optimized for high voltage systems to deliver ultra low noise and low quiescent current. Regulator ground current increases only slightly in dropout, further prolonging the input system life. The LP3995also works with low-ESR ceramic capacitors, reducing the amount of board space necessary for power applications, critical in hand-held wireless devices. The other features include ultra low dropout voltage, high output accuracy, current limiting protection, and high ripple rejection ratio.
应用
◆PMP/PDA/MP3 players
◆Cellular and Mobile phone RF Module
◆Sensor Module
数据参数
数据参数
输出电流(mA)
200
输出电压(V)
3.0/3.3/3.6/5
输入电压(V)
2.5-35
电源抑制比(dB)
-55
精度(%)
2
导通压差(mV/mA)
600 @ 100
静态电流(uA)
3
特点
Low Quiescent
封装
SOT-89/SOT23-3
特征
特征
◆Ultra-Low-Noise for RF Application
◆Input Voltage up to35V
◆Low Dropout : 600mV @ 100mA
◆Output Current ≥200mA
◆Ultra-Fast Response in Line/Load Transient Current Limiting and Thermal Shutdown
