The LP5311 is a power switch device provides full protection to systems and loads which may encounter input over-voltage conditions. The device contains a 30mΩ MOSFET which can operate over an input voltage range from 3.0V to 30V. The OVP
will disconnect VIN and VOUT when the voltage on VIN is higher than over voltage threshold. Switch is controlled by an active-low logic pin. Thermal shutdown protection is integrated which shuts off the switch to prevent damage to the part when the temperature is higher than threshold. LP5311 is available in space-saving SOT23-6 packag
