The LPM4953 integrates two P-Channel enhancement MOSFET Transistor. It uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge. This device is suitable for using in DC-DC conversion, power switch and chargingcircuit. Standard Product LPM4953 is Pb-free and Halogen-free.
应用
◆ Driver for Relay, Solenoid, Motor, LED etc. ◆ DC-DC converter circuit ◆ Power Switch ◆ Load Switch ◆ Charging
数据参数
数据参数
封装
SOP-8
DS电压最大值(V)
-30
GS电压最大值(V)
±12
VGS（TH） -TYP(V)
-1.7
输出电流(A)
5
RDSON (mΩ) at VGS=2.5V （TYP)
-
RDSON (mΩ) at VGS=2.5V （MAX)
-
RDSON (mΩ) at VGS=4.5V （TYP)
65
RDSON (mΩ) at VGS=4.5V （MAX)
80
RDSON (mΩ) at VGS=10V （TYP)
42
RDSON (mΩ) at VGS=10V （MAX)
50
Category
Trench
特征
特征
◆ Trench Technology ◆ PMOS: VDS=-15V RDS(ON) < 65mΩ, ID=3.6A @ VGS=-4.5V RDS(ON) < 42mΩ, ID=5A @ VGS=-10V ◆ Super high density cell design ◆ Extremely Low Threshold Voltage ◆ Small package SOP-8
