Filterless 30W Class F Mono Audio Amplifier With AGC function
规格书下载
转存邮件
LPA2101
转存邮件
概述
The LPA2101 is a 30W, class F mono audio amplifier integrated Class AB/D optional mode and AGC function.It is capable of delivering 29watts of continuous average power to a 4Ω BTL load with less than 10% distortion (THD) from a 15V DC power supply. It offers low THD+N, allowing it to achieve high-quality Power Supply sound reproduction.The LPA2101 device is fully protected against faults with short-circuit protection and thermal protection. Faults are reported back to the processor to prevent devices form being damaged during overload conditions.
应用
◆ Mini-Micro Component, Speaker Bar, Docks ◆ After-Market Automotive ◆ Consumer Audio Applications, CRT TV ◆ Portable Bluetooth Speaker ◆ Cellular and Smart mobile phone ◆ Square Speaker
数据参数
数据参数
输入电压(V)
4.3~15.5
工作类型
Class F
通道数量
1
电源抑制比(dB)
-73
输出功率
30W,15V@4Ω,10%
关断电流(uA)
12
特点
Non-Crack Noise (NCN) function,Differential input,Low THD+N,Enough output power
封装
ESOP8
特征
特征
◆ Wide voltage range: 4.3V-15.5V ◆ 550KHz fixed frequency switching for amplifier ◆ 29W Output at 10% THD with a 4Ω Load and 15V VDD for amplifier ◆ 19W Output at 10% THD with a 4Ω Load and 12V VDD for amplifier ◆ Integrated Self-Protection Circuits Including, Under-Voltage, Over-Temperature, and Short Circuit ◆ High Efficient Class-D Operation: >86% ◆ Filterless, Low Quiescent Current and Low EMI ◆ Pb-Free Package
