The LPM9031 is a dual channel MOSFET, which combines advanced trench MOSFET technology with a low resistance package to provide extremely low RDS(ON).This device is suitable for use as a load switch or in PWM applications.
应用
◆ Driver for Relay, Solenoid, Motor, LED etc. ◆ DC-DC converter circuit ◆ Power Switch ◆ Load Switch ◆ Charging
数据参数
数据参数
封装
SOP8
DS电压最大值(V)
30
VGS电压最大值(V)
±12
VGS（TH） -TYP(V)
1.05
输出电流(A)
5.8
RDSON (mΩ) at VGS=2.5V （TYP)
24
RDSON (mΩ) at VGS=2.5V （MAX)
52
RDSON (mΩ) at VGS=4.5V （TYP)
19
RDSON (mΩ) at VGS=4.5V （MAX)
33
RDSON (mΩ) at VGS=10V （TYP)
18
RDSON (mΩ) at VGS=10V （MAX)
28
Category
Trench
特征
特征
◆ 100% EAS Guaranteed ◆ Green Device Available ◆ Super Low Gate Charge ◆ Excellent CdV/dt effect decline ◆ Advanced high cell density Trench technology
